| VSS |
Model
Solenoid Pilot Operated Directional
Contraol Valves |
型式
電磁先導方向控制閥 |
| 10 |
Nominal Size and Mounting Surface
10:1/4"
ISO 4401 size 10
NFPA-D10
CETOP size 10
DIN 24340 NG32 |
口徑及組裝面型式
10:1/4"
ISO 4401 size 10
NFPA-D10
CETOP size 10
DIN 24340 NG32 |
| C2 |
Spool Type
Check on "Spool Types" page |
心軸型式
請參閱"心軸型式"頁面 |
| P |
Pilot Type
Blank:Omit for intemal pilot
(standard)
P:Extemal pilot |
導壓型式
無：內導(標準)
P:外導 |
| D |
Drain Type
Blank:Omit for intemal drain
(standard)
D:Extemal drain |
洩油型式
無：內洩(標準)
D:外洩 |
| U |
Thread for bolts and female thread on
pilot valve mounting surface
(For details see Specification and Dimensions
for each size)
Blank:omit for metric thread
U:UNC thread |
螺絲規格
(詳細請參照規格及尺寸圖)
無：公制牙(標準)
U:UNC美規牙
|
| A |
Main Spool Stroke Limiter
Blank:Omit for standard type
A:Equipped on A port end
B:Equipped on B port end
W:Equipped on A&B port ends |
中座行程調整器
無：標準
A:附在"A"孔側
B:附在"B"孔側
W:附在"A","B"孔側 |
| 10 |
Design Number
10 Series |
設計號
10系列 |
