| VS |
Model
Solenoid Directional Contraol Valves |
型式
電磁方向控制閥 |
| 03 |
Nominal Size and Mounting Surface
02:3/8"
ISO 4401 size 05
NFPA-D05
CETOP size 5
DIN 24340 NG10 |
口徑及組裝面型式
02:3/8"
ISO 4401 size 05
NFPA-D05
CETOP size 5
DIN 24340 NG10 |
| C2 |
Spool Type
Check on "Spool Types" page |
心軸型式
請參閱"心軸型式"頁面 |
| A1 |
Coil Type
A1:AC110v60Hz A2:AC220v60Hz
A3:AC380v50Hz A4:AC110v50Hz
A5:AC220v50Hz A6:AC240v50Hz
D1:DC12 D2:DC24
R1:AC110V with rectifier
R2:AC220V with rectifier
*For other coil types,consult Hydromax. |
線圈型式
A1:AC110v60Hz A2:AC220v60Hz
A3:AC380v50Hz A4:AC110v50Hz
A5:AC220v50Hz A6:AC240v50Hz
D1:DC12 D2:DC24
R1:AC110V 附整流器
R2:AC220V 附整流器
*如需其他線圈請洽聖譽。 |
| T |
Wiring
T:Terminal box connector with
indicating lights
C:ISO4400(DIN43650)Plug-in
electric connector with indicating lights.
*For other ISO 4400(DIN 43650
connector),consult Hydromax. |
接線型式
T:接線盒+指示燈
C:ISO4400(DIN 43650)牛角型+指示燈
*如需其他牛角型接頭，請洽聖譽。 |
| U |
Bolt Thread
Blank:omit for Metric Thread (Size:M6x35L)
U:UNC thread
(Size 1/4"-20UNC x13/8") |
螺絲規格
無：M6x35L
U:UNC美規牙
(1/4"-20UNC x13/8") |
| 10 |
Design Number
10 Series |
設計號
10系列 |
